This FlySky FS-i4X 2.4GHz 4CH AFHDS R/C Transmitter + FS-A6 Receiver radio system uses a high gain and high-quality multi-directional antenna, it covers the whole frequency band. Associated with a high sensitivity receiver, this radio system guarantees a jamming free long-range radio transmission. Each transmitter has a unique ID when binding with a receiver, the receiver saves that unique ID and can accept only data from the unique transmitter, this avoids picking another transmitter signal and dramatically increase interference immunity and safety.
With strong initiative and passive anti-interference ability and V-MIX mix control system, compatible with many models. According to your own needs, you can DIY expansion channel, this item can be expanded to 10CH. Works in the frequency range of 2.405 to 2.475GHz.This band has been divided into 140 independent channels.
This radio system uses low power electronic components and sensitive receiver chip. The RF modulation uses intermittent signal thus reducing even more power consumption. AFHDS2A system has the automatic identification function, which can switch automatically current mode between the single-way communication mode and two-way communication mode according to the customer needs.
AFHDS2A has built-in multiple channel coding and error-correction, which improve the stability of the communication, reduce the error ratio and extend the reliable transmission distance
Item specifics.
- Use: Vehicles & Remote Control
- Remote Control Peripherals/Devices: Remote Controller
- RC Parts & Accs: Transmitters
- Model Number: FS-I4X
- Material: Plastic
Specifications
Transmitter:
- Item Name: FS-i4X(Latest Released Model)
- Mode(optional): Mode 1 (Right Hand Throttle), Mode 2 (Left-Hand Throttle)
- Default Mode: Mode 2
- Band Range: 2.4055-2.475GHz
- Band Amount: 140
- No. of Channel: 4
- Model Type: RC Airplane/Glider/Helicopter
- RF Power: <20dBm
- Bandwidth: 500KHz
- 2.4GHz System: AFHDS 2A / AFHDS
- Modulation Type: GFSK
- Stick Resolution: 1024
- Low Voltage Warning: <4.2V
- DSC Port: PS2 PPM
- Antenna Length: 26mm *2
- Weight: 335g
- Power: 6V DC 1.5AA*4(Not included)
- Display: LED Indicators
Receiver:
- Item Name: FS-A6
- No. of Channels: 6
- Model Type: Fixed-Wing/Glider/ Helicopter
- RF Range: 2.4055-2.475GHz
- RF Channel: 140
- RF Receiver Sensitivity: -105dBm
- Bandwidth: 500KHz
- 2.4GHz System: AFHDS 2A
- Modulation Type: GFSK
- Power: 4.0-6.5V DC
- Antenna Length: 26mm
Package Includes:
1 x FS-i4X 2.4GHz 4CH AFHDS R/C Transmitter
1 x FS-A6 Receiver
1 x User Manual
